022207 - ACIERA 22 VG

Price on request

Condition: NEW· Manufacturer: Aciera· Country: Switzerland

Description

{"Table length": "650 mm", "Table width": "320 mm", "Drill capacity in steel": "22 mm", "Drill capacity in cast-iron": "24 mm", "Depth of throat": "300 mm", "Drill depth (spindle stroke)": "120 mm", "Spindle head adjustment": "300 mm", "Table travels:": "", "Longitudinal travel (X-axis)": "330 mm", "Transversal travel (y-axis)": "210 mm", "Vertical travel (z axis)": "350 mm", "Spindle speeds:": "", "stepless": "", "from": "0.12 mm/t", "up to": "0.6 mm/t", "Feeds:": "", "Voltage 50 Hz 3x": "380 Volt", "Spindle motor": "2 CV", "Machine's weight about": "990 kg", "Overall dimensions machine:": "", "Length": "1100 mm", "Width": "600 mm", "Height": "2100 mm", "Various accessories:": "", "Threading device": "", "Drill chuck": "1 - 13 mm", "Quick change device": ""}

Send Enquiry

Seller

Muller Machines SA
