020664 - HAUSER S 40 CNC

Description

{"Table length": "770 mm", "Table width": "630 mm", "Table load max.": "500 kg", "Longitudinal travel (X-axis)": "650 mm", "Transversal travel (y-axis)": "450 mm", "Verticla travel (W-axis)": "500 mm", "Max. grinding diameter": "230 mm", "with display-plate": "360 mm", "Stroke of spindle-nose": "125 mm", "Max. angle with taper grinding:": "", "up to": "80000 t/min", "up to grinding depth": "44 mm", "Alternating stroke mouvement, infinitely adjust.": "", "from Vmin.": "1 mm/min", "up to Vmax.": "12000 mm/min", "Stroke frequency Z": "4 Hz", "Radiale fine feed U-axis up to": "6 mm", "Planetary motion speeds: c axis": "", "stepless": "", "from": "4500 t/min", "Possible grinding-spindle speeds:": "", "With air-turbine max.": "160000 t/min", "Voltage 50 Hz 3x": "380 Volt", "Machine's weight about": "5600 kg", "Overall dimensions machine:": "", "Length": "2650 mm", "Width": "2000 mm", "Height": "3150 mm"}
