023241 - SCHAUBLIN 102 TM CNC

Description

{"Number of axis total": "3", "Centre height": "102 mm", "Swing over cross-slide": "75 mm", "Swing over bed": "125 mm", "Max. turning diameter": "19 mm", "Taper in spindle": "W25", "Spindle hole": "28.6 mm", "Turning length": "100 mm", "Carriage:": "", "Longitudinal travel (Z-axis)": "100 mm", "Cross travel (x-axis)": "120 mm", "Main spindle:": "", "C axis (spindle,resolution)": "0.0015 \u00b0", "Spindle speeds:": "", "stepless": "", "from": "50 t/min", "up to": "5000 mm/min", "Tailstock:": "", "Morse taper": "2 CM", "Feeds:": "", "longitudinal from": "mm/min", "transversal from": "mm/min", "Rapid traverse:": "7 m/min", "Spindle motor": "2.2 kW", "Voltage 50 Hz 3x": "380 Volt", "Total power required": "8 kVA", "Machine's weight about": "650 kg", "Overall dimensions machine:": "", "Length": "1400 mm", "Width": "800 mm", "Height": "1470 mm", "3-jaw chuck": "", "Coolant system": "", "Set of centers": "", "Quick change tool": "TRIPAN", "Set of steel holders": ""}
