023083 - KELLENBERGER KEL-VARIA 2RU 225/1500

Description

{"Centre height": "225 mm", "Distance between centres": "1500 mm", "Max. grinding diameter": "432 mm", "Workpiece weight on centres max.": "150 kg", "Grinding weehl left side:": "", "Diameter": "500 mm", "Width": "80 mm", "Bore": "127 mm", "Grinding wheel right side:": "", "B axis resolution max.": "0.1 \u00b0", "Grinding wheel speeds:": "", "stepless": "", "from": "8 t/min", "up to": "800 t/min", "Swivelling range": "+10 / -230 \u00b0", "Peripheral speed": "45 m/s", "Work piece spindle head:": "", "speeds:": "", "Holding taper:": "5 CM", "Permitted load capacity": "160 Nm", "Tailstock:": "", "Hydraulic return": "", "con regolazione micrometrica": "", "Taper in tailstock:": "4 CM", "Spindle stroke": "50 mm", "Pressure": "200 - 700 N", "Voltage 50 Hz 3x": "400 Volt", "Various accessories:": "", "Thread grinding cycles": "KEL-ASSIST 100", "Coolant through spindle (cts)": "", "Paper filtration system": "", "C axis": "", "B axis": "", "Electrical measuring instrum.": "MOVOMATIC", "Tool measuring device": "KEL-SET", "Measuring feeler gauge": "MOVOMATIC C25", "Dressing device on the upper table": "", "Grinding device on the undertable": "", "Swivelling diamond holder": "", "Balancing attachment": "", "Automatic balancing device": "KEL-BALANCE", "Macnetic chuck diameter": "400 mm", "Softwarepack (to form)": ""}
