022837 - PROTH PSGS-2550AH

Description

{"Table length": "500 mm", "Table width": "250 mm", "Max. distance from table": "", "to spindle-centreline": "500 mm", "Longitudinal travel (X-axis)": "600 mm", "Cross travel (z-axis)": "280 mm", "Transversal travel (y axis)": "mm", "Vertical travel (Y-axis)": "340 mm", "Table speeds:": "", "stepless": "", "from": "5 m/min", "up to": "25 m/min", "Grinding wheel speeds fix": "2900 t/min", "Diameter of grinding wheel": "350 mm", "Width of the grinding wheel": "25 mm", "Drilling cap. of grind.wheel": "31.75 mm", "Voltage 50 Hz 3x": "400 Volt", "Grinding spindle motor": "2 CV", "Machine's weight about": "1350 kg", "Overall dimensions machine:": "", "Length": "500 mm", "Width": "250 mm", "Height": "1900 mm", "Various accessories:": "", "Paper filtration system": "", "Magnetic plate:": "", "Redressing device": "", "Lamp": ""}
