022773 - ABA EL 1006

Description

{"Table length": "1000 mm", "Table width": "500 mm", "Grinding length": "1000 mm", "Grinding width": "600 mm", "Table load max.": "1000 kg", "to spindle-centreline": "700 mm", "Longitudinal travel (X-axis)": "1300 mm", "Cross travel (z-axis)": "600 mm", "Transversal travel (y axis)": "530 mm", "Automatic longitudinal feeds:": "", "stepless": "", "from": "1000 t/min", "up to": "2600 t/min", "Automatic cross-feed:": "", "Automatic vertical feed:": "", "Diameter of grinding wheel": "400 mm", "Width of the grinding wheel": "60 mm", "Max. grinding wheel width": "80 mm", "Wheel int. diameter": "127 mm", "Grinding wheel speeds:": "", "Fine feed:": "", "Smallest step": "1 \u00b5m", "Air connect": "6 bar", "Voltage 50 Hz 3x": "400 Volt", "Grinding spindle motor": "11 kW", "Machine's weight about": "5600 kg", "Overall dimensions machine:": "", "Length": "1000 mm", "Width": "500 mm", "Height": "1850 mm", "Various accessories:": "", "Coolant system": "250 l", "Paper filtration system": "", "Magnetic plate:": "", "Redressing attachment hydraulic": "", "Central lubrification": "", "Oil mist extractor": "AIRTECH", "Handwheel electroinic": ""}
