SALVAGNINI,P4-2516 CNC PANEL BENDER,MFG:2009

Description

TC30155F.CT.RPC+PCD3015.RVA.VE1.Motax+P4X-2516.LS.LI.ABA30/400/130.ZL.ZTL.WK.SPA.NS.CLA/A1500.CUT.P.ULC001.UC1500.UPCUT01+SAP271618.POS+SIX.NT+JOB.CONSOLE+RC+Office.P4TC30155F.CT.RPC- Table with moveable top (Loading)PCD3015.RVA.VE1.MOTAX- Part Centering and Destacking DeviceP42516- MachineLS.LI.ABA30/400/130.Zl.ZTL.WK.SPA.NS.CLA/A1500.CUT.p.ULC001.UC1500.UPCUT01-Tooling, CLA Blades and Cut OptionSAP271618.POS- Parts accumulator (Unloading)SIX.INT+JOB.CONSOLE+RC- Software on the machine (Standard)Office.P4- Offline Software (Not Included)SpecificationsMaximum length of incoming sheet (mm): 2795Maximum width of incoming sheet (mm): 1524Max. diagonal that can be rotated (mm): 2800Maximum bend length (mm): 2500Maximum bend height (mm): 165Minimum thickness (mm): 0.5Max. thickness and bend angle: 2.5 ( 90)steel, UTS 410 N/mm2 (mm): 2.1 ( 135)Max. thickness and bend angle: 2.1 ( 90)stainless steel, UTS 580 N/mm2 (mm): 1.6 ( 130)Max. thickness and bend angle: 3.2 ( 90)Aluminum, UTS 265 N/mm2 (mm): 2.5 ( 130)
