FORCE ONE TC-3523 x 2300mm CNC Slant Bed Lathe with Fanuc Series 0i-TD Control. Year 2012.

Description

Swing over bed 660mm. Swing over cross slide 480mm. Maximum turning dia. 500mm. Maximum turning length 2315m. X/Z travel 250 +25mm/2250mm. Rapids X/Z 12/15m/min. Feed rates X/Z 0.001mm/500mm/min. Spindle nose A2-11. Spindle speeds (Geared) Low to 625 rpm (High) to 2500 rpm. Spindle Motor Power (continuous) 22kW. Spindle Motor Power (30 minutes) 26kW. Bar capacity 116mm. Fitted with 385mm dia. 3 jaw chuck. 12 station turret. 2 x Fixed steadies 210mm dia & 410mm dia. capacity. Tailstock dia/stroke 110mm/100mm. Tailstock Taper No.5MT.  Turret  tooling. Oil Cooler. Transformer. Swarf Conveyor. Fanuc Series 0i-TD Control. Machine Manuals. Machine dimensions L x W x H 5924mm (6824mm with swarf conveyor) x 2130mm x 2235mm high. Approximate weight 13,700 kg.
