022179 - MAKINO EDNC 30F

Description

{"Table length": "500 mm", "Table width": "350 mm", "Number of spline": "4", "T-channel width": "10 mm", "Distance of the T-slots": "80 mm", "Table load max.": "500 kg", "Longitudinal traverse (X-axis)": "300 mm", "Cross traverse (Y-axis)": "250 mm", "Height adjustment (Z-axis)": "250 mm", "max. electrode weight": "50 kg", "Dielectric aggregate:": "", "Contents": "60 l", "Length": "2800 mm", "Width": "2200 mm", "depth": "300 mm", "Rapid traverse:": "20 m/min", "Voltage 50 Hz 3x": "400 Volt", "Machine's weight about": "4100 kg", "Overall dimensions machine:": "", "Height": "2300 mm", "Various accessories:": "", "C axis": "\u00b0"}
